Please use the most recent tagged release. The include and src directory now report 100% line and branch coverage although a few things were exempted.

Overview

People say that you should not micro-optimize. But if what you love is micro-optimization... that's what you should do. - Linus Torvalds

libhatchet is a fast-compiling, lightweight, bespoke C17/C++23 alternative to the C++ standard library designed for cross-compilation to resource-constrained targets like DSPs, FPGAs, ASICs or WebAssembly. It also falls back to requiring only C99 libraries and a C++11 compiler, and deliberately avoids dependencies on the C++ standard library. For those with a low-level mindset, the developer experience is better than with the C++ standard library. For example, the template instantiation errors are easier to read, and hxassertmsg will format your assert messages before setting a breakpoint for you. There is nothing unnecessary to step through in the debugger.

banner

Compile times are shockingly fast when using ninja+ccache without needing precompiled headers. A C++20 module is also available in the src directory and is recommended although modules load a little slower with GCC.

The implementation maintains compatibility with every sensible warning flag and with sanitizers for both GCC and Clang. Of course, asserts are also widely used. The implementation also avoids dynamic allocations except when initializing system allocators.

Key Features

Library hardening and asserts are controlled via HX_HARDENING_MODE. E.g. usage is -DHX_HARDENING_MODE=HX_HARDENING_MODE_STANDARD. See <hx/libhatchet.h> for the different kinds of asserts available. Note: Checks against null are only provided at the debug level of hardening.
- HX_HARDENING_MODE_NONE: Omits library hardening and disables all asserts.
- HX_HARDENING_MODE_STANDARD: Provides hardening but saves space by omitting verbose output. Meets the requirements of the C++ standard.
- HX_HARDENING_MODE_VERBOSE: Provides verbose messages, suitable for internal release. Meets the requirements of the C++ standard.
- HX_HARDENING_MODE_DEBUG: Provides comprehensive asserts and verbose output.
Portability: libhatchet can easily be made to run on top of any old embedded C99 library. musl libc is recommended for embedded Linux and is widely packaged: https://musl.libc.org/. No other C++ runtime or C++ code is required. pthreads or C11's <threads.h> may be used for threading, which are widely implemented standards. See .clang-tidy for a discussion of linting rules and portability concerns. All public symbols (aside from methods and fields) start with either HX or hx. All non-public symbols in the headers end with an underscore. A subset of the Google Test macros is also optionally provided.
Profiling System: Uses processor cycle sampling to create a hierarchical timeline capture compatible with Chrome's chrome://tracing viewer (navigation uses W, A, S, and D keys). One line of assembly may be needed for uncommon hardware.
Memory Management: Fast and deterministic. Supports various allocation semantics, particularly valuable for applications where crashing from memory fragmentation is unacceptable. If you have a lot of temporary allocations, this system reasonably offers 30% memory and 30% performance improvements overall with just a few RAII scopes added. Complex applications are supported using an array of variable sized stacks. Fancy tools like heaptrack can also be used by disabling the memory manager with -DHX_USE_MEMORY_MANAGER=0. Leak tracking is provided.
Console: Provides an embedded command processor with automatic C++ function binding using templates. Useful for interactive target debugging without recompilation and also provides support for config files or configuration via the command-line. Syntax is just verb [arg ...].
Testing Framework: Safer, lighter, debuggable reimplementation of core Google Test functionality.
Task Queue: An unopinionated task queue with priorities and a worker pool. An execution graph is also available as a layer on top.
Containers: Provides a set of containers designed for environments where reallocation is not allowed. This codebase is intended for low-level work where the standard container libraries cause code bloat, memory fragmentation, and poor cache coherence. If those are not your concerns, consider using additional libraries. No tree data structures will be provided. For efficiency reasons exceptions are not supported and therefore noexcept is widely applied to defend against data loss due to the unexpected use of exceptions.

There are two array classes that both support two allocation modes:

	compile time capacity > 0	hxallocator_dynamic_capacity
hxarray	Compile-time fixed size, inline storage	Variable initial size, non-resizable, non-reallocating heap storage [1]
hxvector	Resizable, fixed capacity, inline storage	Resizable, variable initial capacity, non-reallocating heap storage

[1] Not provided by the standard.

See the headers at include/hx/ for the remaining containers. They generally use the same names as the standard.

Pretty Printers: Implements GDB-compatible pretty printers, enabling debuggers and most code editors to display container contents in a human-readable format.
Algorithms: This implementation is designed to use the __restrict keyword wherever appropriate. See <hx/hxalgorithm.hpp> for standard algorithms and <hx/hxsort.hpp> for comparison based sorting and lookup. Radix sorting with <hx/hxradix_sort.hpp> is recommended for Θ(n) sorting. Less common functions have been omitted to reduce compile time. Random access iterators are required for a lot of things but the only relational operator used is <. This codebase tries not to give an AI rope to hang itself with. Showing inner-loop assembly to an AI is also advised.
Smart Pointers: Due to the non-dynamic allocation focus shared and weak pointers are not provided. However, hxhandle_table is provided for weak references. hxptr implements std::unique_ptr. hxoptional implements std::optional providing optional temporary allocation semantics with safe access semantics without the temporary allocation. hxref is a non-owing pointer wrapper that provides the same safe access semantics.
Performance Focus: This is systems code. Everything should be optimized and cache-coherent without causing code bloat. This codebase avoids exceptions and RTTI for efficiency. Exceptions will be caught by the test driver and the console if they are enabled and make it that far. __restrict is used extensively. Inlining attributes are used to make inner loops flatter as is standard practice with standard libraries.
C99 Compatibility: Logging, asserts, and memory management are available in plain C99 via <hx/libhatchet.h>.
64-bit Ready: Designed for both 32-bit and 64-bit targets. hxsize_t is a signed type because that enables important optimizations. It is equivalent to ptrdiff_t but could be converted to 32-bit on a 64-bit platform if desired.
Fast builds: Blazing fast builds when used with ccache and no .pch. ninja + ccache is recommended when using cmake. Precompiled headers have surprisingly long load times and break ccache's optimizations. One warning though, this is also accomplished by skipping less commonly used features.
AI Friendly: Things with the same name as the standard generally work the same way as the standard. This means that AI is easily able to apply its existing knowledge of standard C++. It also already knows how to use the test macros when writing tests. Using tabs instead of spaces reduces token use.
constexpr ready: C++11 constexpr is used where possible. Asserts, algorithms, hxconstexpr_list, hxbitset and hxrandom support consteval in C++23.

Documentation

The documentation is at https://whatchamacallem.github.io/libhatchet.

Running the command doxygen with no arguments will generate docs/index.html. The markdown source for the documentation is in the header files at include/hx/ and is also readable as-is. The stylesheet was tested with Doxygen 1.15.0.

Reading <hx/hxsettings.h> is recommended. There are a number of important things that can be configured on the compiler command line. E.g. whether or not the library is wrapped in a namespace.

Not Provided

This project was started for the author's own personal use, and it tries to be complete enough for ordinary C++ programmers. It was started before a lot of similar functionality was added to the standard. However, if you find something missing, odds are your favorite AI already knows how to add it, or it was omitted because the C library was deemed sufficient.

That said, some functionality of the C++ standard library is not worth reimplementing here. If you need these things you are advised to use the standard library shipped with your compiler.

Atomics. The C version of <stdatomic.h> is incompatible with g++.
Iterators Library. This codebase intentionally deemphasizes iterators.
Ranges Library. This would be a large and pointless rewrite.
Strings Library. These are allocation intensive. See the {fmt} project.

Other Projects

musl libc - This is the recommended C library for use with libhatchet in a freestanding environment.
{fmt} - Has a micro-optimized version of std::format. Also has nice features like console colors and a fast printf too.

Tested Environments

Almost every reasonable GCC and Clang warning flag should be safe to enable. Clang-Tidy is also in use. The environment tested with every release is glibc and musl on Ubuntu 26.04 LTS using g++-16 and clang-22. g++-10 and clang-11 are periodically tested with C++11. The latest MSVC 2022 should be working with most warnings enabled as well. Although the MSVC static analyzer is not being tested. See debian_packages.sh to install the required packages for the test scripts on a Debian based distribution (e.g. Ubuntu).

The pico directory contains a port to the Raspberry Pi Pico 2. Note how there is almost nothing to do when porting as libc provides almost all of the device abstraction required. Some devices may require you to explicitly call the C++ global constructors before calling main() yourself. Check the sample code that came with your board.

The scripted builds exercise the following toolchains, language modes, and HX_HARDENING_MODE combinations:

Script	Toolchain	Language Modes	HX_HARDENING_MODE	Notes
debugbuild.sh	clang/clang++	C17, C++23	3	32-bit debug build with ccache and no exceptions/RTTI.
testcmake.sh	cmake + default compiler	C17, C++23	3	Uses the real Google Test and runs hxtest and Clang-Tidy.
testcoverage.sh	gcc, g++ + --coverage	C99, C++23	3	Enables HX_TEST_ERROR_HANDLING=1 and emits coverage_details.html.
testmatrix.sh	gcc, clang (ASan/UBSan/TSan/MSan)	C99, C17, C++11, C++23	0-3	Sweeps optimization levels and sets HX_USE_THREADS=1/11.
teststrip.sh	musl-gcc (static)	C17, C++11/14/17/20/23	0	Size-focused static build with allocator/library stripping.
testwasm.sh	emcc	Emscripten defaults (Clang-based C/C++)	3 (default)	WebAssembly build with the memory manager disabled and pthreads enabled.

testall.sh runs all of the above and also enforces certain naming conventions.

testmsvc.bat tests 32 and 64-bit configurations of debug and release on Windows. The currently installed version of MSVC should be automatically discovered.

debugbuild.sh and teststrip.sh will detect when C++23 is missing and fall back to C++20 for testing g++-10 and clang-11.

Project Structure

The scripts are at the top level for easy access.

📁 .vscode - The vscode configuration files.
📁 example - Simple program showing usage.
📁 gdb - GDB scripts for the container classes.
📁 include - This is the directory to add to your include path.
- 📁 hx - These are all the <hx/hx*> header files.
  - 📁 detail - These are internal header files.
📁 src - C/C++ files that have to be added to your build.
📁 test - An optional test suite.
